Road Reimagined

Go long, go short, go fast. This is WorldTour performance for real world rides.

What it's for

Comfortable high-performance road riding, long distance missions, fast group rides

Highlights

• Lightweight, smoothly compliant, sleekly aero Synapse carbon frameset with StashPort downtube storage

• Smooth, consistent, reliable 2x12-speed shifting from Shimano's trusted 105 mechanical drivetrain

• DT Swiss 470 rims with Vittoria Zaffiro Pro V 32c tires - grip, durability, and speed

• Cannondale Conceal stem routes cables neatly through the headtube for reduced drag and sleek looks

Specs

Frameset

• Frame
  • Synapse Carbon, Proportional Response construction, integrated cable routing, downtube Stashport, 12x142 thru-axle, UDH, BSA 68mm threaded BB, flat mount disc, integrated seat binder, SmartSense Gen 2.0 compatible, fender mounts
• Fork
  • Synapse Carbon, integrated crown race, 12x100mm thru-axle, flat mount disc, internal routing, 1-1/8" to 1-1/5" Delta steerer, 55mm offset, fender mounts
• Headset
  • Integrated, 1-1/8" - 1-1/2"

Drivetrain

• Rear Derailleur
  • Shimano 105 7100
• Front Derailleur
  • Shimano 105 7100, braze-on
• Shifters
  • Shimano 105 7100, 12-speed
• Chain
  • Shimano 105 7100, 12-speed
• Crank
  • Shimano 105 7100, BSA, 50/34: 165mm (44cm), 170mm (48-51cm), 172.5 (54-56cm), 175mm (58-61)
• Rear Cogs
  • Shimano 105 7100, 11-36, 12-speed
• Bottom Bracket
  • Shimano BSA 68

Brakes

• Brakes
  • Shimano 105 7170 hydraulic disc, 160/160 RT70 rotors
• Brake Levers
  • Shimano 105 7100

Wheels

• Rims
  • DT Swiss R470 db, 28h
• Spokes
  • Stainless Steel, 14g
• Tire Size
  • 32
• Wheel Size
  • 700
• Hubs
  • (F) Shimano RS470, 12x100mm centerlock / (R) Shimano RS470, 12x142mm centerlock
• Tires
  • Vittoria Zaffiro Pro V, 700x32c

Components

• Handlebar
  • Vision Trimax Aero Alloy: 400mm (44-51cm), 420mm (54-61cm)
• Stem
  • Cannondale C1 Conceal, Alloy, 31.8, -6°: 80mm (44-48m), 90mm (51cm), 100mm (54-56cm), 110mm (58-61cm)
• Grips
  • Cannondale Bar Tape, 3.5mm
• Saddle
  • Fizik Terra Argo X7, 150mm
• Seatpost
  • HollowGram 27, Alloy, 2 bolt clamp, 330mm, 15mm offset
