Faster everywhere

The all-new SuperSix EVO destroys expectations. So light, so fast, and so aero, it defies logic. This is a machine built to make you faster everywhere. Speed has evolved.

Where it thrives

Racing, the red zone, the pointy end, the podium

What it's for

Breakaways, KOMs, Podiums, and PRs

Highlights

• Lightweight, low-drag SuperSix EVO carbon frameset – the ideal blend of speed, handling and comfort

• Shimano 105 Di2 12-speed - Shimano's workhorse high-performance electronic shifting road group

• DT-Swiss R470 rims - light, wide and reliable aluminum wheels

• Vision Trimax Aero bars and Cannondale C1 Conceal stem - ergonomic, low-drag cockpit with hidden cables


Specs

Frameset

• Frame
  • SuperSix EVO Carbon, integrated cable routing w/ Switchplate, 12x142 Syntace thru-axle, BSA 68mm threaded BB, flat mount disc, integrated seat binder, SmartSense compatible

• Fork
  • SuperSix EVO Carbon, integrated crown race, 12x100mm Syntace thru-axle, flat mount disc, internal routing, 1-1/8" to 1-1/4" Delta steerer, 55mm offset (44-54cm), 45mm offset (56-61cm)

• Headset
  • Integrated, 1-1/8" - 1-1/4"


Drivetrain

• Rear Derailleur
  • Shimano 105 Di2 R7150

• Front Derailleur
  • Shimano 105 Di2 R7170

• Shifters
  • Shimano 105 Di2 R7170, wireless, 2x12

• Chain
  • Shimano 105, 12-speed

• Crank
  • Shimano 105 R7100, 50/34

• Rear Cogs
  • Shimano 105 R7100, 11-34, 12-speed

• Bottom Bracket
  • Shimano BB-RS500, BSA


Brakes

• Brakes
  • Shimano 105 7170 hydraulic disc, 160/160 RT70 rotors

• Brake Levers
  • Shimano 105 Di2 R7170 hydraulic disc


Wheels

• Rims
  • DT Swiss R470 DB, 28h

• Spokes
  • Stainless Steel, 14g

• Tire Size
  • 25
• Wheel Size
  • 700
• Hubs
  • (F) Formula CL-712, 12x100mm centerlock / (R) Formula RXC-400, 12x142mm centerlock

• Tires
  • Vittoria Rubino Pro Bright Black, 700x25c, reflective strip


Components

• Handlebar
  • Vision Trimax Aero

• Stem
  • Cannondale C1 Conceal, Alloy, 31.8, -6°

• Grips
  • Cannondale Bar Tape, 3.5mm

• Saddle
  • Prologo Nago RS STN, Stainless Steel Rails

• Seatpost
  • Cannondale C1 Aero 40 Carbon, 0mm offset (44-48cm), 20mm offset (51-61cm)
