• Hookless rim technology offers XC-level impact resistance by providing a more consistent carbon fiber structure at the rim wall. It also creates a rounder tire shape for better grip and sidewall support when cornering.

• Precision reinforced carbon lay-up places carbon fiber only where needed, creating a super strong and lightweight rim.
• 25mm inner width and hookless rim construction offer a shorter, wider tire contact patch for reduced power loss and increased impact absorption.

• A wide inner width supports higher volume road and gravel tires, allowing lower tire pressures and more confident handling.

• High-tensile-strength, ultralight CADEX carbon spokes and precision reinforced carbon lay-up combine for class-leading stiffness-to-weight.

• Custom tuned Dynamic Balanced Lacing (DBL) technology sets spokes at a wider bracing angle and evens out tension under pedaling force, producing a stiffer, more efficient wheel with outstanding power transfer.

• CADEX ceramic bearings offer 1.5x smoother action than steel.

• Lightweight CADEX R2-C60 hub with R-Drive features a DLC 60-tooth ratchet driver, durable flat spring and redesigned dust cover for instant engagement and long-lasting efficiency.

• Integrated front hub design reinforces axle support and eliminates play by replacing end cap, bearing and bushing interface with an integrated axle running the length of the hub.

Specs

• Rim Material
  • Carbon

• Rim Type
  • Hookless Clincher
• Tubeless
  • CADEX Tubeless System (rim tape and valve included)
• Rim Height
  • 35mm
• Rim Outer Width
  • 31mm
• Rim Inner Width
  • 25mm
• ETRTO
  • 622-25
• Front Hub
  • CADEX R2-C60 Hub, Centerlock
• Rear Hub
  • CADEX R2-C60 Hub, 60T Ratchet Driver, Centerlock
• Freehub System

  • R-Drive
• Hub Compatibility
  • SRAM XDR / SHIMANO HG / CAMPAGNOLO N3W
• Bearing
  • CADEX Ceramic Bearings
• Front Axle
  • 100x12 Thru Axle

• Rear Axle
  • 142x12 Thru Axle

• Spokes (Front)
  • Aero Carbon Spoke
• Lacing (Front)
  • 21H
• Spokes (Rear)
  • Aero Carbon Spoke
• Lacing (Rear)
  • 24H
• Warranty
  • 2 Years
• Incident Replacement
  • 5 Year (registered original owner only)

• Weight (Pair)
  • 1270g
