The mountain bike experience starts here. With a redesigned frame that’s now lighter and more durable, along with a smooth-riding suspension fork, thru-axle hubs*, and a 1x drivetrain*, this aluminum hardtail is everything an aspiring MTB rider needs to evolve and advance. *on select models

Modern MTB Design

Tapered fork steerer tubes*, quality components including a 1x drivetrain* with clutch-equipped rear derailleurs, thru-axle hubs*, internal cable routing (including dropper seatpost) and an integrated chainstay protector give aspiring trail riders room to grow. *on select models

Off-Road Control

New geometry is optimized for confident trail riding and two different wheel sizes (27.5 or 29-inch) depending on frame size. The geometry is also designed for front suspension with either an 80mm or 100mm fork depending on frame size. All models have clearance for high-volume tires (up to 2.4-inch) for traction and grip on technical terrain.

Light and Durable

All-new ALUXX aluminum frame features updated shaping and a lighter overall weight for improved performance on off-road terrain.

Specs

• Frame

  • ALUXX-grade aluminum, disc
• Fork

  • SXC32-2 RCL, air spring, thru axle, steel steerer, 15x110 XS: 80mm travel (27.5) S: 80mm travel (27.5) / 100mm travel (29) M:100mm travel (29) L: 100mm travel (29) XL: 100mm travel (29) XXL: 100mm travel (29)
• Shock
  • N/A
• Handlebar

  • Giant Connect Trail, 31.8mm XS: 690mm (27.5) S: 690mm (27.5) / 750mm (29) M: 780mm (29) L: 780mm (29) XL: 780mm (29) XXL: 780mm (29)
• Grips

  • Giant Sole-O
• Stem

  • Giant Sport, 7-degree XS: 40mm (27.5) S: 50mm (27.5) / 50mm (29) M: 60mm (29) L: 70mm (29) XL: 80mm (29) XXL: 90mm (29)
• Seatpost

  • Giant Contact Switch Core, 30.9 XS: 100x350mm (27.5) S: 100x350mm (27.5) / 100x350mm (29) M: 120x400mm (29) L: 120x400mm (29) XL: 120x400mm (29) XXL: 120x400mm (29)
• Saddle

  • Giant ErgoContact Trail
• Shifters

  • Shimano Deore M6100, 1x12
• Front Derailleur

  • N/A
• Rear Derailleur

  • Shimano Deore M6100, clutch
• Brakes

  • Shimano BR-MT200, hydraulic, Shimano RT-10 rotors [F]180mm, [R]160mm
• Brake Levers

  • Shimano BL-MT200
• Cassette

  • Shimano Deore M6100, 10x51
• Chain

  • KMC X12
• Crankset

  • ProWheel MPX, 32t (27.5) or 30t (29) XS: 165mm (27.5) S: 165mm (27.5) / 170mm (29) M: 170mm (29) L: 170mm (29) XL: 175mm (29) XXL: 175mm (29)
• Bottom Bracket

  • cartridge
• Rims

  • Giant GX03V 29 or 27.5, alloy, double wall, 21mm inner width
• Hubs

  • [F] Shimano, sealed bearing, 15x110 thru axle, [R] 12x142 thru-axle
• Spokes

  • stainless, 14g
• Tires

  • Maxxis Rekon 27.5x2.4" or Maxxis Rekon Race 29x2.4", wire bead
• Extras

  • 2.4" max tire size
• Max Tire Clearance

  • 2.4"
