Long Live Aero

It’s hard to beat the sensation of power that comes from a great aero bike. What rider is ambivalent about a machine that is designed to give back free watts? Is there a competitor who doesn’t grasp every last advantage in the battle for speed?

Orca Aero is built for pure speed and efficiency, with aerodynamic shaping, exceptional power transfer, and razor-sharp handling. Its race-focused geometry puts you in the perfect position to push harder, ride faster, and hold nothing back.

Advanced Aerodynamics

Aligning the frame with the airflow, optimizing cross-sections, smoothing transitions and myriad other improvements mean a big reduction in drag.

Power and Precision

There’s no doubt about it—a frame that’s stiff in the right places transfers more of your watts to the rear wheel. Your power, converted to speed. That same stiffness also delivers razor-sharp handling, giving you precise control when it matters most—whether you're cornering at speed or holding your line in a sprint.

Dynamic Race Handling

Race-focussed geometry and ergonomics put you in the perfect place to perform at any speed.

Specs

Frameset

Frame

Orbea Orca Aero Carbon OMX disc, monocoque construction, HS 1,5", BB 386, powermeter compatible, Thru Axle 12mm x 142mm rear, thread M12x2 P1, Speed release compatible, internal cable routing, EC/DC compatible.

Fork

Orbea Orca Aero OMX ICR, full carbon, 1-1/8" - 1,5" tappered head tube compatible, Thru axle 12x100mm, thread M12x2 P1, Speed release compatible dropout.

Steerer tube

FSA 1-1/2" Integrated Aluminium Cup

Drivetrain

Crankset

Shimano Ultegra R8100 36x52t

Shifters

Shimano ST-8170

Cassette

Shimano Ultegra R8100 11-30t 12-Speed

Rear derailleur

Shimano Ultegra Di2 R8150

Front derailleur

Shimano Ultegra Di2 R8150

Chain

Shimano M8100

Cockpit

Handlebar

Integrated Bar and Stem OC SH-RA10, Road Aero Carbon, Reach 80, Drop 125

Brakes

Brakes

Shimano R8170 Hydraulic Disc

Rotors

160mm Front /140mm Rear

Brakes Configuration

N/A

Wheels

Wheels

Oquo Road Performance RP45LTD

Tyres

Vittoria Corsa N.Ext G2.0 Foldable 700x28c

Front Wheel Axle

Orbea Thru Axle 12x100mm M12x2 P1 Lite

Rear Wheel Axle

Orbea Thru Axle 12x142mm M12x2 P1 Lite

Components

Seatpost

OC Road Aero RA10 Carbon Ultralight, SB0/25, w/Micro tilt adjustment

Saddle

Prologo Scratch-M5 Pas T2.0 size 140mm

Accessories

Handlebar Tape

Orbea Anti-Slippery/Shock Proof

Hydration

OC Aero Bottle RA10 (550ml) + Carbon Cage Kit RA10

Storage

OC Aero Toolbox TB01PP
