Balanced power and efficiency, built with intention for aggressive trails; made by people who love to ride.
At just 1.92 kg, the TQ HPR60 system is the lightest, quietest, and smallest in its class. With 60Nm of torque, 350W of maximum power, and 200% support, it’s a mid-power drive system that focuses on optimal power-to-weight ratio and maximum efficiency. At 580Wh, the battery has a higher capacity than other drive systems of its size, and with near invisible integration and unchanged bike kinematics you can hardly tell it’s there.
The same confidence-inspiring suspension as the rest of the Sight family, VPSHP is the ideal high pivot all-mountain setup with smooth, efficient pedalling and confident handling in rough, steeper terrain.
Details:
- TQ motor is the smallest drive system in its class – with highest torque for its size
- Looks and feels like a pedal bike — with extra support to ride more
- All-mountain geometry with uncompromised ride quality across sizing.
- High pivot flow to eat up rough terrain with confidence.
- Personalized support and automatic updates through the TQ app and software.
- Ride Aligned™ - Perfect fit, dialed handling and personalized setup in minutes
Build Kit:
| Frame |
Carbon Frame, 150mm Travel, UDH, Eagle Transmission Compatible, Ride Aligned™ |
| Fork |
Fox 36 Performance Elite GripX2, HSC/LSC/HSR/LSR, 160mm, 44mm Offset, Fender Included |
| Rear Shock |
Fox Float X Performance, 230x60mm Std, 2 position |
| Rear Shifter |
Shimano Deore Di2 SW-M6250-IR, 12sp |
| Rear Derailleur |
Shimano Deore Di2 RD-M6250, SGS, 12sp |
| Crankset |
e*thirteen Helix Race Alloy TQ, 34T, 155mm (S1,S2) - 160mm (S3,S4,S5) |
| Cassette |
Shimano Deore CS-M6100-12, 10-51T, 12sp |
| Chain |
Shimano Deore CN-M6100, 12sp |
| Front Brake |
Shimano Deore M6120 4-P, Metallic pads |
| Front Brake Rotor |
Shimano SM-RT86, 203mm, 6-Bolt |
| Rear Brake |
Shimano Deore M6120 4-P, Metallic pads |
| Rear Brake Rotor |
Shimano SM-RT86, 180mm, 6-Bolt |
| Brake Levers |
Shimano Deore M6100 |
| Handlebar |
Norco 6061 DB Alloy, 800mm, 25mm Rise |
| Stem |
Norco Alloy, 40mm Length, 35mm Clamp |
| Seatpost |
TranzX YSI08 RAD+ Travel Adjust Dropper, 31.6mm, 125mm (S1) -150mm (S2) -170mm (S3) -200mm (S4, S5) |
| Headset |
FSA No.55 Sealed Bearing, 1 1/8" - 1.8" Tapered, ( ZS44/28.6 | ZS56/40 ) |
| Saddle |
WTB Rocket Fusion Med, 142x250 mm |
| Grips |
WTB Wavelength, 140mm Length |
| Seatpost Clamp |
Norco Alloy Nutted Clamp, 34.9mm ID |
| Front Hub |
Crank Bros. Synthesis, 15x110mm Boost, 32h, 6-Bolt |
| Rear Hub |
Crank Bros. Synthesis, 12x148mm Boost, Micro Spline, 32h, 6-Bolt |
| Rims |
Crank Bros. Synthesis Alloy Enduro, F- 31.5mm 28h, R- 29.5mm 32h, 29"-27.5" F/R |
| Front Tire |
Continental Kryptotal-F, Enduro, Soft, 29" x 2.4", Foldable |
| Rear Tire |
Continental Xynotal, Enduro, Soft, 27.5" x 2.4", Foldable |
| Spokes/Nipples |
Sapim D-Light (front), Sapim Race (rear) |
| Drive Unit |
TQ HPR60, 60 Nm |
| Battery |
TQ 580Wh |
| Switch |
TQ Remote, V02, 22.2mm |
| Sensor |
TQ Speed Sensor Rotor Magnet |
