2025 Cannondale Moterra 4

From Cannondale
SKU: C65234U10SM
$5,699.00
Size
Colour
Wheel Size

Stock Locations:

St. Laurent:

Hintonburg:

Warehouse:

Special Order:

Description

More Juice, No Excuse

The Moterra packs massive power, range, and silky suspension, handling rugged terrain like a luxury off-roader. Built to go further—faster.

Model Description

Moterra 4 strips things down to the essentials—reliable, rugged, and ready for anything. A SmartForm C1 Alloy frame with a RockShox Deluxe Select shock and rugged Suntour Zeron 36X fork deliver a ride that is balanced, planted and predictable. Bosch’s most powerful CX motor and big 600Wh battery deliver smooth, sustained power, with more than enough range to keep things interesting. A Shimano CUES U6000 drivetrain and Tektro Gemini SL 4-piston brakes handle the stops and shifts, making this an always-game partner for off-road exploration and all-day excursions.

What it's for

Endless spins, uphill wins, and permanent grins on all kinds of trails, from the mild to the wild

Highlights

  • A premium SmartForm C1 Alloy frame - light, stiff, and guaranteed for life
  • Climb-crushing strength and natural feeling power delivery from Bosch's most powerful motor, the Performance CX
  • Interchangeable 600Wh battery provides an ideal balance of range and light weight
  • Smooth-riding SR Suntour Zeron 36-X Boost 160mm fork, and RockShox Deluxe Select air shock
  • Precise shifting from Shimano’s CUES U6000 LinkGlide 11-speed drivetrain
  • Strong, controllable braking from Tektro Gemini SL 4-piston hydraulic disc brakes with 203mm rotors

Frameset

  • Frame
    Moterra, SmartForm C1 Alloy, 29" wheels, 150mm travel, Cannondale Tuned Suspension, removable downtube battery, alloy skid plate, 55mm chainline, internal cable routing, 148x12mm thru-axle, UDH, 200mm native post mount brake, 1.5” – 1.8” tapered headtube, 40mm two-bolt kickstand compatible, integrated Moterra rear rack and fender mounts
  • Fork
    SR Suntour Zeron 36-X Boost, 160mmm, EQ Air, compression & rebound adjust, 15x110mm thru-axle, tapered steerer, 44mm offset
  • Headset
    Acros ICR, 1.5" to 1.8", sealed bearings
  • Rear Shock
    RockShox Deluxe Select, DebonAir+, adjustable rebound, 230x62.5mm

E-System

  • Drive Unit
    Bosch Performance Line CX
  • Battery
    Bosch PowerTube, 600Wh
  • Charger
    Bosch 4A
  • Display
    Bosch LED Remote

Drivetrain

  • Rear Derailleur
    Shimano CUES U6000, LinkGlide
  • Shifters
    Shimano CUES U6000, 11-speed, LinkGlide
  • Chain
    Shimano LG500, LinkGlide, 11-speed
  • Crank
    FSA Bosch E-bike w/ 55mm chainline, 160mm, 34T
  • Rear Cogs
    Shimano CUES LG400, LinkGlide, 11-50, 11-speed

Brakes

  • Brakes
    Tektro Gemini SL 4-piston hydraulic disc, 203mm rotors
  • Brake Levers
    Tektro Gemini SL hydraulic disc

Wheels

  • Rims
    WTB ST i30 TCS, 30mm inner width, 32h, tubeless compatible
  • Spokes
    DT Swiss Champion 2.0
  • Tire Size
    2.4
  • Wheel Size
    29
  • Hubs
    (F) Shimano TC500, 15x110mm thru-axle / (R) Shimano TC500, 12x148mm thru-axle, centerlock
  • Tires
    Schwalbe Magic Mary Performance, 29x2.4", Addix Foldable, Tube
  • Front Tire
    (F) Schwalbe Magic Mary Performance, 29x2.4", Addix Foldable, TLR
  • Rear Tire
    (F) Schwalbe Magic Mary Performance, 29x2.4", Addix Foldable, TLR

Components

  • Handlebar
    Cannondale 3 riser, 6061 Alloy, 25mm rise, 8° sweep, 4° rise, 800mm
  • Stem
    Cannondale 1, 6061 Alloy, 35.0, 40mm, 0°
  • Grips
    Cannondale TaperRidge
  • Saddle
    WTB Silverado Medium
  • Seatpost
    Cannondale DownLow Dropper, internal routing, 34.9, 150mm (S), 170mm (M), 200mm (L), 230mm (XL)
